INLET VACUUM FILTERS – SOLBERG 235P – 400 – 4″ outlet

INLET VACUUM FILTERS – SOLBERG 235P – 400 – 4″ outlet

27″ tall, 12″ diameter 4″ inlet, 52 lbs.

Polyester Replacment element 235P

Features
99%+ removal efficiency standard Polyester: 5 microns, Paper: 2 microns
Fully drawn weatherhood – no welds to rust or vibrate apart
Low entry velocity air gap between base and cover
Durable heavy gauge base with low pressure drop bracket and pipe design
Durable carbon steel construction with baked enamel finish
Interchangeable elements
Temp (continuous): min -15° F ( -26° C) max 220° F (104° C)
Filter change out differential: 10″-15″ in. H2O above initial delta P
Pressure drop graphs available upon request
Less maintenance
Center bracket located for minimal flow restriction
